Intelligent Fully Automatic Digital Vickers Hardness Tester XHVT-5Z/10Z/30Z/50Z /V3.0, CCD system

China Intelligent Fully Automatic Digital Vickers Hardness Tester XHVT-5Z/10Z/30Z/50Z /V3.0, CCD system supplier
Intelligent Fully Automatic Digital Vickers Hardness Tester XHVT-5Z/10Z/30Z/50Z /V3.0, CCD system supplier Intelligent Fully Automatic Digital Vickers Hardness Tester XHVT-5Z/10Z/30Z/50Z /V3.0, CCD system supplier

Large Image :  Intelligent Fully Automatic Digital Vickers Hardness Tester XHVT-5Z/10Z/30Z/50Z /V3.0, CCD system

Product Details:

Place of Origin: CHINA
Brand Name: RAYTECH
Certification: ISO CE
Model Number: XHVT-5Z/10Z/30Z/50Z /V3.0

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Standard Export Carton
Delivery Time: 5~8 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500units per month
Contact Now
Detailed Product Description
Product Name: Intelligent Digital Vickers Hardness Tester, Touch Screen With CCD System XHVT-5Z/10Z/30Z/50Z Test Force: 0.2kgf~49N, 0.5kgf~490N
Test Range: 1HV~2967HV Loading Method: Automatic (Loading/Dwell/Unloading)
Objective: 10× 20× 40× Resolution: 0.06μm,0.03μm,0.015μm



Intelligent Fully Automatic Digital Vickers Hardness Tester



XHVT-5Z/10Z/30Z/50Z /V3.0, CCD system



Intelligent Fully Automatic Digital Vickers Hardness Tester   XHVT-5Z/10Z/30Z/50Z /V3.0, CCD system



Main Function:



This instrument is a new generation of automatic Vickers hardness tester. It adopts the integrated design of hardness tester and panel computer; With Windows 7 operating system, it has all functions of computer. With CCD image acquisition system, it can show the indentation image directly on the touch screen and automatically get the Vickers hardness value. It takes over the old method of measuring the diagonal length by eyepiece, avoids the stimulation and visual fatigue of the light source of the eyepiece, and protects the eyesight of the operator. It is a major innovation of Vickers hardness tester.

· All the testing parameters can be selected on the side panel computer. With touching screen, it operates quickly and conveniently and displays clearly and intuitively.

· With CCD image acquisition system, it shows the image clearly and gets the hardness value just by touching the screen.

· Automatic recognition and shifting between the objective and the indenter, automatically get the Vickers hardness value.

· With the function of hardness scale conversion.

· The system has two languages: English and Chinese.

· With USB, VGA and LAN interfaces, the hardness measurement can be print out by USB interface.

· It can automatically save the measuring data, generate the hardness-depth curve and save as WORD or EXCEL document.

· With motorized X-Y test table, automatic focusing and automatic measuring, it realizes the fully automation of Vickers hardness testing.



Application range:



Suitable for ferrous metal, non-ferrous metals, IC thin sections, coatings, ply-metals; glass, ceramics, agate, precious stones, thin plastic sections etc.; hardness testing such as that on the depth and the trapezium of the carbonized layers and quench hardened layers.



Technical Specification:



Model XHVT-5Z / 10Z / 30Z / 50Z / V3.0
Test Force Kgf,N
XHVT-5Z / V3.0

0.2kgf, 0.3kgf, 0.5kgf, 1kgf, 2kgf, 2.5kgf, 3kgf, 5kgf

1.96N, 2.94N, 4.90N, 9.80N, 19.6N, 24.5N, 29.4N, 49N

XHVT-10Z / V3.0

0.2kgf, 0.3kgf, 0.5kgf, 1kgf, 2kgf, 2.5kgf, 3kgf, 5kgf, 10kgf

1.96N, 2.94N, 4.90N, 9.80N, 19.6N, 24.5N, 29.4N, 49N, 98N

XHVT-30Z / V3.0

0.3kgf, 0.5kgf, 1kgf, 2kgf, 2.5kgf, 3kgf, 5kgf, 10kgf, 20kgf, 30kgf

2.94N, 4.90N, 9.80N, 19.6N, 24.5N, 29.4N, 49N, 98N, 196N, 294N

XHVT-50Z / V3.0

0.5kgf, 1kgf, 2kgf, 2.5kgf, 3kgf, 5kgf, 10kgf, 20kgf, 30kgf, 50kgf

4.90N, 9.80N, 19.6N, 24.5N, 29.4N, 49N, 98N, 196N, 294N, 490N

Test Range 1HV~2967HV
Loading Method Automatic (Loading/Dwell/Unloading)
Shifting between Objective and Indenter Automatic Shifting
Computer CPU: Intel I3,Memory: 2G,SSD: 32G
CCD Pixel 1.30 Million
Conversion Scale HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HS, HBW
Hardness Reading Indentation Displaying and Automatic Measuring on Touch Screen
Data Output WORD or EXCEL Report with Curve Chart
Objective 10× ,20× ,40×
Total Magnification 100× ,200× ,400×
Resolution 0.06μm,0.03μm,0.015μm
Dwell Time 0~60s
Light Source Halogen Lamp
Motorized X-Y Test Table Size: 110×110mm; Travel: 50×50mm; Resolution: 0.002mm
Max. Height of Specimen 185mm
Throat 130mm
Power Supply AC220V,50Hz
Execute Standard ISO 6507,ASTM E92,JIS Z2244,GB/T 4340.2
Dimension 560×335×675mm,Packing Dimension: 650×380×960mm
Weight Net Weight: 52kg,Gross Weight: 67kg


Packing List:



Name Qty Name Qty
Instrument Main Body 1 set Diamond Vickers Indenter 1 pc
10×,20×,40× Objective each 1 pc Motorized Cross Test Table 1 pc
Power Cable 1 pc Horizontal Regulating Screw 4 pcs
Level 1 pc Fuse 1A 2 pcs
Halogen Lamp 12V,15~20W 1 pc Screw Driver 1 pc
Inner Hexagon Spanner 2.5mm 1 pc Hardness Block 700~800 HV1 1 pc
Hardness Block 400~500 HV5 1 pc Anti-dust Cover 1 pc
Usage Instruction Manual 1 copy
