Magnetic Yoke Flaw Detector, MT Yoke, Magnetic Particle Testing Equipment
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Product Name: | Magnetic Yoke Flaw Detector, MT Yoke, Magnetic Particle Testing Equipment | Charging Power Supply: | 220V 50Hz |
|---|---|---|---|
| Operating Current: | AC1.4A | Magnetic Electrode Distance: | 0~200mm |
| Probe Weight: | 3.1kgs | Probe: | 208×52×146 |
Magnetic Yoke Flaw Detector, MT Yoke, Magnetic Particle Testing Equipment
Technical Parameters
|
Model parameters
|
RCDX-220 Magnetic Yoke Flaw Detector |
RCDX-220AC/DC Magnetic Yoke Flaw Detector |
|
|
Power supply |
/ | 110/220V 50Hz 12V | |
|
Charging power supply |
220V 50Hz | 110/220V 50Hz | |
|
Using battery |
/ | MF12—7.2AH | |
|
Operating current |
AC1.4A |
AC1.4A DC1.7A |
|
|
Charging time |
/ | 8~15h | |
|
Battery life |
/ | More than 6 hours | |
|
Working interval
|
1 minute switch on 1 minute off | 1 minute switch on 1 minute off | |
|
Magnetic electrode distance |
0~200mm | 0~200mm | |
|
Lifting power
|
A C |
>5.5kg | >5.5kg |
|
D C |
/ | >26kg | |
|
Weight
|
Probe |
3.1kg | 3.1kg |
|
Battery package |
/ | 2.9kg | |
|
Outline dimension(㎜) |
Probe |
208×52×146 | 208×52×146 |
|
Battery package |
/ | 160×70×100 | |
|
Charger |
/ | 75×50×40 | |
TAG: Magnetic Yoke Flaw Detector MT Flaw Detector Permanent Magnet Yoke
