Low Frequency Vibration Meter, Handheld Vibration Meter, Separate sensor VM908L 1Hz-10kHz

China Low Frequency Vibration Meter, Handheld Vibration Meter, Separate sensor VM908L 1Hz-10kHz supplier
Low Frequency Vibration Meter, Handheld Vibration Meter, Separate sensor VM908L 1Hz-10kHz supplier Low Frequency Vibration Meter, Handheld Vibration Meter, Separate sensor VM908L 1Hz-10kHz supplier

Large Image :  Low Frequency Vibration Meter, Handheld Vibration Meter, Separate sensor VM908L 1Hz-10kHz

Product Details:

Place of Origin: China
Brand Name: Raytech
Certification: ISO CE
Model Number: VM908L

Payment & Shipping Terms:

Minimum Order Quantity: 1unit
Packaging Details: Standard Export Carton
Delivery Time: 5days
Payment Terms: Western Union, T/T, L/C
Supply Ability: 5000units per month
Contact Now
Detailed Product Description
Product Name: Low Frequency Vibration Meter, Handheld Vibration Meter, Separate Sensor VM908L 1Hz-10kHz Displacement: 4-500Hz(±5%); 2.5-4Hz(±10%); 1-1000Hz(3dB)
Velocity: 4-1000Hz(±5%); 2.5-4Hz(±10%); 1-2000Hz(3dB) Acceleration: 4-1000Hz(±5%); 2.5-5000Hz(±10%); 1-10000Hz(3dB)
High Frequency Acceleration: 1000-5000Hz(±10%);5000-10000Hz(3dB) Weight: 200g





Low Frequency Vibration Meter, Handheld Vibration Meter,



Separate sensor VM908L 1Hz-10kHz





Low Frequency Vibration Meter, Handheld Vibration Meter, Separate sensor VM908L 1Hz-10kHz





Features:



Measuring vibration for low rotation speed machine,such as Hydro Turbine, Wind



Turbine and Rotary Kiln



Small size, transducer included,battery powered, external accelerometer



One button control both power and measurement. Very easy for use.



3 1/2 LCD digital display, sampling per second.



Holding function.



Automatic power off.



True RMS measurement.



Suitable for monitoring machinery vibration caused by imbalance,misalignment, gear



& bearing faults and etc.




Specifications:



Amplitude Ranges:



Displacement 0.01-19.99 mm Eq. peak-peak





Velocity 0.1-199.9 mm/s true RMS





Acceleration 0.1-199.9 m/s2 or 20g Eq.Peak





High Frequency Acceleration: 0.1-199.9 m/s2 Eq. Peak



Temperature range



0-50oC



Frequency response& Accuracy



Displacement: 4-500Hz(±5%); 2.5-4Hz(±10%); 1-1000Hz(3dB)





Velocity: 4-1000Hz(±5%); 2.5-4Hz(±10%); 1-2000Hz(3dB)





Acceleration: 4-1000Hz(±5%); 2.5-5000Hz(±10%); 1-10000Hz(3dB)





High Frequency Acceleration: 1000-5000Hz(±10%);5000-10000Hz(3dB)



Battery



9V 6F22/Rechargeable, 25/10 hours of continuous operation.



Pickup



Accelerometer with handheld probe and/or magnetic mount



Dimensions



13×6×2.3cm



Weight



200g





Optional Intrinsically safe version with internal accelerometer








TAG:   Gear Faults Monitor
